สอนวิธีใช้งาน Spinner บน Android

1
// Top-level build file where you can add configuration options common to all sub-projects/modules.
2

3
buildscript {
4
    ...
5
    dependencies {
6
        classpath 'com.android.tools.build:gradle:0.13.0'
7
    }
8
}
9
...

1
...
2
distributionUrl=http\://services.gradle.org/distributions/gradle-2.1-all.zip

1
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
2
    android:layout_width="match_parent"
3
    android:layout_height="match_parent"
4
    android:padding="32dp"
5
    android:orientation="vertical">
6

7
    <Spinner android:layout_width="wrap_content"
8
             android:layout_height="wrap_content"
9
        android:id="@+id/english_club">
10

11
    </Spinner>
12

13
    <Spinner android:layout_width="wrap_content"
14
             android:layout_height="wrap_content"
15
             android:layout_marginTop="16dp"
16
             android:id="@+id/thai_club">
17

18
    </Spinner>
19

20
</LinearLayout>

1
package com.devahoy.android.spinnerdemo;
2

3
import android.app.Activity;
4
import android.os.Bundle;
5
import android.widget.Spinner;
6

7
import java.util.ArrayList;
8

9

10
public class MyActivity extends Activity {
11

12
    private Spinner mEnglishSpinner;
13
    private Spinner mThaiSpinner;
14

15
    private ArrayList<String> mThaiClub = new ArrayList<String>();
16

17
    @Override
18
    protected void onCreate(Bundle savedInstanceState) {
19
        super.onCreate(savedInstanceState);
20
        setContentView(R.layout.activity_my);
21

22
        mEnglishSpinner = (Spinner) findViewById(R.id.english_club);
23
        mThaiSpinner = (Spinner) findViewById(R.id.thai_club);
24

25
        createThaiClubData();
26
    }
27

28
    private void createThaiClubData() {
29

30
        mThaiClub.add("Air Force Central");
31
        mThaiClub.add("Army United");
32
        mThaiClub.add("Bangkok Glass");
33
        mThaiClub.add("Bangkok United");
34
        mThaiClub.add("BEC Tero");
35
        mThaiClub.add("Buriram United");
36
        mThaiClub.add("Chainat Hornbill");
37
        mThaiClub.add("Chiangrai United");
38
        mThaiClub.add("Chonburi");
39
        mThaiClub.add("Muangthong United");
40
        mThaiClub.add("Osotspa Saraburi");
41
        mThaiClub.add("Police United");
42
        mThaiClub.add("PTT Rayong");
43
        mThaiClub.add("Ratchaburi");
44
        mThaiClub.add("Samut Songkhram");
45
        mThaiClub.add("Singhtarua");
46
        mThaiClub.add("Sisaket");
47
        mThaiClub.add("Songkhla United");
48
        mThaiClub.add("Supanburi");
49
        mThaiClub.add("TOT Bangkok");
50

51
    }
52
}

1
<string-array name="club">
2
    <item>Arsenal</item>
3
    <item>Aston Villa</item>
4
    <item>Burnley</item>
5
    <item>Chelsea</item>
6
    <item>Crystal Palace</item>
7
    <item>Everton</item>
8
    <item>Hull City</item>
9
    <item>Leicester City</item>
10
    <item>Liverpool</item>
11
    <item>Manchester City</item>
12
    <item>Manchester United</item>
13
    <item>Newcastle United</item>
14
    <item>Queens Park Rangers</item>
15
    <item>Southampton</item>
16
    <item>Stoke City</item>
17
    <item>Sunderland</item>
18
    <item>Swansea City</item>
19
    <item>Tottenham Hotspur</item>
20
    <item>West Bromwich Albion</item>
21
    <item>West Ham United</item>
22
</string-array>

1
@Override
2
protected void onCreate(Bundle savedInstanceState) {
3
    super.onCreate(savedInstanceState);
4
    setContentView(R.layout.activity_my);
5

6
    mEnglishSpinner = (Spinner) findViewById(R.id.english_club);
7
    mThaiSpinner = (Spinner) findViewById(R.id.thai_club);
8

9
    createThaiClubData();
10

11
    // Adapter ตัวแรก
12
    ArrayAdapter<String> adapterThai = new ArrayAdapter<String>(this,
13
            android.R.layout.simple_dropdown_item_1line, mThaiClub);
14
    mThaiSpinner.setAdapter(adapterThai);
15

16

17
    // Adapter ตัวที่สอง
18
    String[] englishClub = getResources().getStringArray(R.array.club);
19
    ArrayAdapter<String> adapterEnglish = new ArrayAdapter<String>(this,
20
            android.R.layout.simple_dropdown_item_1line, englishClub);
21
    mEnglishSpinner.setAdapter(adapterEnglish);
22
}

1
// setOnItemSelectedListener
2
mThaiSpinner.setOnItemSelectedListener(new AdapterView.OnItemSelectedListener() {
3
    @Override
4
    public void onItemSelected(AdapterView<?> parent, View view, int position, long id) {
5
        Toast.makeText(MyActivity.this,
6
                "Select : " + mThaiClub.get(position),
7
                Toast.LENGTH_SHORT).show();
8
    }
9

10
    @Override
11
    public void onNothingSelected(AdapterView<?> parent) {
12

13
    }
14
});
15
mEnglishSpinner.setOnItemSelectedListener(new AdapterView.OnItemSelectedListener() {
16
    @Override
17
    public void onItemSelected(AdapterView<?> parent, View view, int position, long id) {
18
        Toast.makeText(MyActivity.this,
19
                "Select : " + englishClub[position],
20
                Toast.LENGTH_SHORT).show();
21
    }
22

23
    @Override
24
    public void onNothingSelected(AdapterView<?> parent) {
25

26
    }
27
});

1
<?xml version="1.0" encoding="utf-8"?>
2

3
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
4
              android:orientation="horizontal"
5
              android:layout_width="match_parent"
6
              android:padding="16dp"
7
              android:layout_height="match_parent">
8

9
    <ImageView android:layout_width="32dp"
10
               android:layout_height="32dp"
11
               android:src="@drawable/ic_launcher"
12
               android:layout_gravity="center"
13
               android:id="@+id/logo"/>
14

15
    <TextView android:layout_width="match_parent"
16
              android:layout_height="wrap_content"
17
              android:text="Title"
18
              android:layout_marginLeft="16dp"
19
              android:layout_gravity="center"
20
              android:id="@+id/name"/>
21

22
</LinearLayout>

1
package com.devahoy.android.spinnerdemo;
2

3
import android.content.Context;
4
import android.view.LayoutInflater;
5
import android.view.View;
6
import android.view.ViewGroup;
7
import android.widget.BaseAdapter;
8
import android.widget.ImageView;
9
import android.widget.TextView;
10

11
import java.util.ArrayList;
12

13
public class CustomAdapter extends BaseAdapter {
14

15
    private Context mContext;
16
    private ArrayList<String> mData;
17
    private LayoutInflater mInflater;
18

19
    public CustomAdapter(Context context, ArrayList<String> data) {
20
        mInflater = LayoutInflater.from(context);
21
        mContext = context;
22
        mData = data;
23
    }
24
    @Override
25
    public int getCount() {
26
        return mData.size();
27
    }
28

29
    @Override
30
    public Object getItem(int position) {
31
        return mData.get(position);
32
    }
33

34
    @Override
35
    public long getItemId(int position) {
36
        return position;
37
    }
38

39
    @Override
40
    public View getView(int position, View convertView, ViewGroup parent) {
41
        ViewHolder holder;
42

43
        if (convertView == null) {
44
            holder = new ViewHolder();
45
            convertView = mInflater.inflate(R.layout.list_item_adapter, parent, false);
46
            holder.name = (TextView) convertView.findViewById(R.id.name);
47
            holder.logo = (ImageView) convertView.findViewById(R.id.logo);
48
        } else {
49
            holder = (ViewHolder) convertView.getTag();
50
        }
51

52
        int imgResourceId;
53
        switch (position) {
54
            case 0:
55
                imgResourceId = android.R.drawable.ic_menu_share;
56
                break;
57
            case 1:
58
                imgResourceId = android.R.drawable.ic_menu_call;
59
                break;
60
            case 2:
61
                imgResourceId = android.R.drawable.ic_menu_camera;
62
                break;
63
            case 3:
64
                imgResourceId = android.R.drawable.ic_menu_search;
65
                break;
66
            default:
67
                imgResourceId = android.R.drawable.ic_menu_zoom;
68
                break;
69
        }
70

71
        holder.name.setText(mData.get(position));
72
        holder.logo.setImageResource(imgResourceId);
73

74
        convertView.setTag(holder);
75

76
        return convertView;
77
    }
78

79
    public class ViewHolder {
80
        TextView name;
81
        ImageView logo;
82
    }
83
}

1
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
2
    android:layout_width="match_parent"
3
    android:layout_height="match_parent"
4
    android:padding="32dp"
5
    android:orientation="vertical">
6

7
    <Spinner android:layout_width="match_parent"
8
             android:layout_height="wrap_content"
9
        android:id="@+id/english_club">
10

11
    </Spinner>
12

13
    <Spinner android:layout_width="match_parent"
14
             android:layout_height="wrap_content"
15
             android:layout_marginTop="16dp"
16
             android:id="@+id/thai_club">
17

18
    </Spinner>
19

20
    <Spinner android:layout_width="match_parent"
21
             android:layout_height="wrap_content"
22
             android:layout_marginTop="16dp"
23
             android:id="@+id/spinner_menu">
24

25
    </Spinner>
26

27
</LinearLayout>

1
// Spinner with CustomAdapter
2
Spinner spinnerMenu = (Spinner) findViewById(R.id.spinner_menu);
3
ArrayList<String> data = new ArrayList<String>();
4
for (int i = 1; i <= 5; i++) {
5
    data.add("Menu#" + i);
6
}
7

8
CustomAdapter customAdapter = new CustomAdapter(this, data);
9
spinnerMenu.setAdapter(customAdapter);
